Single-boiler espresso machine available in 2 or 3 groups with automatic dosing (USB) and Steady Brew (SB) technology.
Dimensions
Width
770 mm / 30.31 inch
Height
520 mm / 20.47 inch
Depth
540 mm / 21.26 inch
Weight
74 kg / 163.14 lb
Adjustable feet: Yes
Max cup height
80 mm / 3 inch
Interface and operations
Digital display
Digital display to control all coffee extraction parameters in real time.
Digital display
With settings menu
Brewing technology
Steady Brew (SB)
Rancilio Steady Brew (SB) technology is the evolution of the traditional thermosiphon system and introduces a set of innovative features designed to improve the performance of all single-boiler espresso machines. By keeping the water temperature stable during extraction, Steady Brew guarantees excellent thermal stability, reliability and maximum repeatability, both during busy periods and in low usage conditions. Rancilio Patented Technology.
T-Switch
Thanks to the 4-position T-Switch knob, a different extraction temperature can be set for each group, even for single boiler coffee machines. With the boiler adjusted to 1.0 bar, a temperature of approx. 88°C, 93°C, 96°C or 98°C can be set on each group and the right extraction temperature for each type of coffee is always available. The T-Switch can only be adjusted by specialised technicians during installation by removing the cup warmer.
Brewing group
Brass
Water
Hot Water Economizer
Hot water wand
X-Tea
Steam
C-lever
The C-lever steam valve is operated by rotating the knob just 25°. Turning it upwards, the valve stays open. Turning it downwards, the valve opens and automatically closes when released.
Cool touch steam wand
The cool touch steam wand is thermally insulated with a double-layered protective coating.
iSteam
The iSteam automatic steam wand features two buttons, both of which can be programmed with the following functions: “Cappuccino”, to heat and froth milk, or “Latte”, to heat only.
Rancilio Patented Technology.
Steam wand
Power
Power supply
208/220-240 V~, 60 Hz 2.9 kW 220-240 V~/380-415 V3N~, 50-60 Hz 4.95 kW
Water supply
Fixed water connection
Hydraulic circuit
Main boiler capacity (steam)
16 liter
Design
Ergonomic Portafilter
The chrome-plated brass portafilter, with an ergonomic handle designed to balance the weight, holds coffee filters up to a capacity of 21 g, ensures stability when pressing, and eases wrist movements for the barista. The portafilter handles may be personalized.
Grid System
The removable cup tray grids are made of a scratch-resistant polymer, which makes them conveniently dishwasher-safe. They are designed to allow coffee residues to flow directly into the drain tray, keeping the working area clean.
LED lights
White LED lights positioned under the group heads provide excellent illumination for the work area.
RGB lights
The aesthetic RGB lights can be customised with different intensities and colours (Classe 20 only). The functional RGB lights on the group covers (Classe 11, Classe 7 USB) and above the control panel (Classe 9) help the operator to monitor the various states of the machine at a glance.
Tall
This version has a taller working area and can accommodate cups up to 14.5 cm in height. It also features an extractable rise plate for traditional espresso cups.
Green
Auto ON-OFF
It is possible to set the automatic on and off times for the machine (Classe 11, Classe 20) or set the automatic on time and the power-on hours (Classe 9, Classe 7) for each day of the week.
BM
BM controls the boiler pressure and, in case of a drop, automatically enables the heating element to return the pressure to the preset level. BM can also stop water from being dispensed until the boiler pressure has returned to a suitable level.
Cleaning & maintenance
Easy clean
Easy Clean manages the cleaning process of the group heads, so it can perform it all automatically. The barista need only start the cycle, and the machine will automatically carry out the washing and rinsing operations.
For all models (except the Classe 5 units), Easy Clean also allows you to schedule a daily alarm (3 alarms for the Classe 11) to warn the user of the need for a cleaning cycle, set an optional block on the machine in the event of a cleaning cycle, and view the history of all cleaning cycles performed.
Hydro Hub
USB
Additional Optionals
Connect
Connect is a powerful IoT solution developed by Rancilio Group, to gather and easily analyze all the value relevant data generated by a single coffee machine or an entire fleet. Via a customizable dashboard with widgets, tables and graphs, Connect gives you a ready to use digital toolkit, to monitor key performance parameters in real time and empower your whole coffee business.
Cup Warmer
The cup warmer keeps all espresso and cappuccino cups at the right temperature at all times.
Pods&Caps
Single-boiler espresso machine available in 2 or 3 raised groups (TALL) with automatic dosing (USB) and Steady Brew (SB) technology.
Dimensions
Width: 770 mm / 30.31 inch, Height: 520 mm / 20.47 inch, Depth: 540 mm / 21.26 inch, Weight: 74 kg / 163.14 lb
Adjustable feet: Yes
Max cup height: 145 mm / 5.70 inch
Interface and operations
Digital display:
Digital display to control all coffee extraction parameters in real time.
Touchscreen: No
Digital display: With settings menu
Brewing technology
Steady Brew (SB)
Rancilio Steady Brew (SB) technology is the evolution of the traditional thermosiphon system and introduces a set of innovative features designed to improve the performance of all single-boiler espresso machines. By keeping the water temperature stable during extraction, Steady Brew guarantees excellent thermal stability, reliability, and maximum repeatability, both during busy periods and in low usage conditions. Rancilio Patented Technology.
T-Switch
Thanks to the 4-position T-Switch knob, a different extraction temperature can be set for each group, even for single boiler coffee machines. With the boiler adjusted to 1.0 bar, a temperature of approx. 88°C, 93°C, 96°C, or 98°C can be set on each group and the right extraction temperature for each type of coffee is always available. The T-Switch can only be adjusted by specialised technicians during installation by removing the cup warmer.
Brewing group: Brass
Water
Hot Water Economizer
Hot water wand: X-Tea
Baristas can programme water dosages and temperature levels via the interface.
Rancilio Patented Technology
Steam
C-lever
The C-lever steam valve is operated by rotating the knob just 25°. Turning it upwards, the valve stays open. Turning it downwards, the valve opens and automatically closes when released.
Cool touch steam wand
The cool touch steam wand is thermally insulated with a double-layered protective coating.
iSteam
The iSteam automatic steam wand features two buttons, both of which can be programmed with the following functions: “Cappuccino”, to heat and froth milk, or “Latte”, to heat only.
Rancilio Patented Technology.
Power
Power supply: 208/220-240 V~, 60 Hz 2.9 kW, 220-240 V~/380-415 V3N~, 50-60 Hz 4.95 kW
Water supply: Fixed water connection
Hydraulic circuit
Main boiler capacity (steam): 11 liters
Design
Ergonomic Portafilter
The chrome-plated brass portafilter, with an ergonomic handle designed to balance the weight, holds coffee filters up to a capacity of 21 g, ensures stability when pressing, and eases wrist movements for the barista. The portafilter handles may be personalized.
LED lights
White LED lights positioned under the group heads provide excellent illumination for the work area.
RGB lights
The aesthetic RGB lights can be customised with different intensities and colours (Classe 20 only). The functional RGB lights on the group covers (Classe 11, Classe 7 USB) and above the control panel (Classe 9) help the operator to monitor the various states of the machine at a glance.
Tall
This version has a taller working area and can accommodate cups up to 14.5 cm in height. It also features an extractable rise plate for traditional espresso cups.
Green
Auto ON-OFF
It is possible to set the automatic on and off times for the machine (Classe 11, Classe 20) or set the automatic on time and the power-on hours (Classe 9, Classe 7) for each day of the week.
BM
BM controls the boiler pressure and, in case of a drop, automatically enables the heating element to return the pressure to the preset level. BM can also stop water from being dispensed until the boiler pressure has returned to a suitable level.
Cleaning & maintenance
Easy clean
Easy Clean manages the cleaning process of the group heads, so it can perform it all automatically. The barista need only start the cycle, and the machine will automatically carry out the washing and rinsing operations.
For all models (except the Classe 5 units), Easy Clean also allows you to schedule a daily alarm (3 alarms for the Classe 11) to warn the user of the need for a cleaning cycle, set an optional block on the machine in the event of a cleaning cycle, and view the history of all cleaning cycles performed.
Hydro Hub
USB
Additional Optionals
Connect
Connect is a powerful IoT solution developed by Rancilio Group, to gather and easily analyze all the relevant data generated by a single coffee machine or an entire fleet. Via a customizable dashboard with widgets, tables, and graphs, Connect gives you a ready-to-use digital toolkit to monitor key performance parameters in real time and empower your whole coffee business.
Cup Warmer
The cup warmer keeps all espresso and cappuccino cups at the right temperature at all times.
Pods&Caps
Single-boiler espresso machine available in 2 or 3 groups with automatic dosing (USB) and Steady Brew (SB) technology.
Dimensions
Width: 1010 mm / 39.76 inch
Height: 520 mm / 20.47 inch
Depth: 540 mm / 21.26 inch
Weight: 85 kg / 187.39 lb
Adjustable feet: Yes
Max cup height: 80 mm / 3 inch
Interface and Operations
Touchscreen: No
Digital display: With settings menu – (Standard)
Brewing Technology
T-Switch – Optional
Allows temperature adjustment per group (88°C, 93°C, 96°C, 98°C); adjustable during installation only
Brewing Group: Brass – Standard
Water
Hot Water Economizer – Optional
Hot water wand – Standard
X-Tea – Standard
Programmable water dosage and temperature via interface (Rancilio Patented Technology)
Steam
C-lever steam valve – Standard
Opens fully with 25° turn; upward for hold-open, downward for auto-close
Cool touch steam wand – Standard
Double-layer thermal insulation
iSteam automatic steam wand – Optional
Programmable for “Cappuccino” (heat + froth) and “Latte” (heat only); Rancilio Patented Technology
Steam wand – Standard
Cup Warmer
Cup Warmer – Optional
Maintains correct temperature for espresso and cappuccino cups
Power
Power supply: 220–240 V~/380–415 V3N~, 50–60 Hz, 6.75 kW
Water supply: Fixed water
Hydraulic circuit
Main boiler capacity (steam): 16 liters
Design
Ergonomic Portafilter – Standard
Chrome-plated brass with ergonomic handle; supports up to 21 g; customizable handles
LED lights (work area) – Standard
White LEDs under group heads
RGB lights – Optional
Aesthetic RGB (Classe 20), functional RGB on group covers (Classe 11, Classe 7 USB), and above control panel (Classe 9); customizable color/intensity
Green Features
Auto ON-OFF – Optional
Set on/off times (Classe 11, Classe 20) or daily schedules (Classe 9, Classe 7)
BM (Boiler Management) – Optional
Automatically maintains boiler pressure; disables water if pressure is low
Cleaning & Maintenance
Easy Clean – Standard
Fully automated cleaning process; scheduling alarms (up to 3 on Classe 11); optional lockout and cleaning history
Hydro Hub – Optional
USB Port – Standard
Additional Optionals
Connect (IoT Dashboard) – Optional
Real-time data monitoring via customizable digital interface
Pods & Caps Kit – Optional
Compatibility with coffee pods and capsules
Single-boiler espresso machine available in 2 or 3 raised groups (TALL) with automatic dosing (USB) and Steady Brew (SB) technology.
Dimensions
Width: 1010 mm / 39.76 inch
Height: 520 mm / 20.47 inch
Depth: 540 mm / 21.26 inch
Weight: 85 kg / 187.39 lb
Adjustable feet: Yes
Max cup height: 145 mm / 5.70 inch
Interface and operations
Digital display to control all coffee extraction parameters in real time.
Touchscreen: No
Digital display: With settings menu
Brewing technology
Steady Brew (SB)
Rancilio Steady Brew (SB) technology is the evolution of the traditional thermosiphon system and introduces a set of innovative features designed to improve the performance of all single-boiler espresso machines. By keeping the water temperature stable during extraction, Steady Brew guarantees excellent thermal stability, reliability, and maximum repeatability, both during busy periods and in low usage conditions. Rancilio Patented Technology.
T-Switch
Thanks to the 4-position T-Switch knob, a different extraction temperature can be set for each group, even for single boiler coffee machines. With the boiler adjusted to 1.0 bar, a temperature of approx. 88°C, 93°C, 96°C, or 98°C can be set on each group and the right extraction temperature for each type of coffee is always available. The T-Switch can only be adjusted by specialised technicians during installation by removing the cup warmer.
Brewing group: Brass
Water
Hot Water Economizer
Hot water wand: X-Tea
Baristas can program water dosages and temperature levels via the interface.
Rancilio Patented Technology
Steam
C-lever
The C-lever steam valve is operated by rotating the knob just 25°. Turning it upwards, the valve stays open. Turning it downwards, the valve opens and automatically closes when released.
Cool touch steam wand
The cool touch steam wand is thermally insulated with a double-layered protective coating.
iSteam
The iSteam automatic steam wand features two buttons, both of which can be programmed with the following functions: “Cappuccino”, to heat and froth milk, or “Latte”, to heat only.
Rancilio Patented Technology.
Steam wand
Power
Power supply: 220-240 V~/380-415 V3N~, 50-60 Hz 6.75 kW
Water supply: Fixed water connection
Hydraulic circuit
Main boiler capacity (steam): 16 liter
Design
Ergonomic Portafilter
The chrome-plated brass portafilter, with an ergonomic handle designed to balance the weight, holds coffee filters up to a capacity of 21 g, ensures stability when pressing, and eases wrist movements for the barista. The portafilter handles may be personalized.
Grid System
The removable cup tray grids are made of a scratch-resistant polymer, which makes them conveniently dishwasher-safe. They are designed to allow coffee residues to flow directly into the drain tray, keeping the working area clean.
LED lights
White LED lights positioned under the group heads provide excellent illumination for the work area.
Tall
This version has a taller working area and can accommodate cups up to 14.5 cm in height. It also features an extractable rise plate for traditional espresso cups.
Green
Auto ON-OFF
It is possible to set the automatic on and off times for the machine (Classe 11, Classe 20) or set the automatic on time and the power-on hours (Classe 9, Classe 7) for each day of the week.
BM
BM controls the boiler pressure and, in case of a drop, automatically enables the heating element to return the pressure to the preset level. BM can also stop water from being dispensed until the boiler pressure has returned to a suitable level.
Cleaning & maintenance
Easy clean
Easy Clean manages the cleaning process of the group heads, so it can perform it all automatically. The barista need only start the cycle, and the machine will automatically carry out the washing and rinsing operations.
For all models (except the Classe 5 units), Easy Clean also allows you to schedule a daily alarm (3 alarms for the Classe 11) to warn the user of the need for a cleaning cycle, set an optional block on the machine in the event of a cleaning cycle, and view the history of all cleaning cycles performed.
Hydro Hub
USB
Additional Optionals
Connect
Connect is a powerful IoT solution developed by Rancilio Group, to gather and easily analyze all the value relevant data generated by a single coffee machine or an entire fleet. Via a customizable dashboard with widgets, tables, and graphs, Connect gives you a ready-to-use digital toolkit, to monitor key performance parameters in real time and empower your whole coffee business.
Cup Warmer
The cup warmer keeps all espresso and cappuccino cups at the right temperature at all times.
Pods&Caps
